Installation and Commissioning of Tecquipment Subsonic Wind Tunnel (AF1300) at IBA Sukkur

Chishty Traders established the Fluid lab at IBA Sukkur Univeristy Sindh, Pakistan in February 2019 and installed Tecquipment Subsonic Wind Tunnel (AF1300). Installation was carried out by our Mechatronics Engineers who have wast experience in this field. We had a great time with people of IBA Univeristy who showed great hospitality as well.

This wind tunnel comes with variety of instrumentation and control. Many optional model are available including,

• Cylinder Model with Tapping (AF1300a)

• NACA 0012 Aerofoil with Tappings (AF1300b)

• NACA 2412 Aerofoil with Flap (AF1300c)

• Set of Two NACA 0012 Aerofoils (AF1300d)

• Flat Plate Drag Model (AF1300e)

• Boundary Layer Model (AF1300f)

• Aircraft Model – Low Wing (AF1300g)

• Aircraft Model – High Wing (AF1300h)

• Three-dimensional Drag Models (AF1300j)

• S1210 Aerofoil (AF1300l)

The Installation Pictures and Video can be found below which show a basic view of installed instrument.

Overview of installed Subsonic Wind Tunnel AF1300
